CB-HFT (LS)
CB-HFT (LS)
CB-HFT (LS) is halogen-free, highly flexible, low shrink temperature and flame-retardant polyolefin heat-shrinkable tubing. A 90oC shrink temperature can reduce the operation time and the risk of damage of temperature sensitive components.
CB-HFT (LS) is an excellent choice for identifying wire and cable bundles, wire terminals and components. Shrinking starts at 65oC, and completes at 95.
Size are some as CB-HFT (600) type
CB-HFT (LS)
| Items | Test methods | Specifications |
| Shrink temperature | Company standard | 90oC |
| Operating temperature range | UL224 | 90oC-125oC |
| Radial shrinking ratio | >= 50oC | |
| Longitudinal change | ASTM D2671 | -5%-+5% |
| Tensile strength | ASTM D638 | >= 10.4MPa |
| Elongation at break | ASTM D638 | >= 200% |
| Anging in circulating-air oven | 158.0 oC +- 1.0 oC, 168hrs | |
| Tensile strength after aging | ASTM D638 | >= 7.3MPa |
| Elongation at break after aging | ASTM D638 | >= 100% |
| Volume resistance | ASTM D2671 | >= 1.0 x 10-2 cm |
| Dielectric strength | UL224, AC2500V, 1min | No breakdown |
| Heat shock | ASTM D638 | No breakdown |
| Flammability | ASTM D2671 | VW-1 |
| Concentricity | ASTM | >= 70% |
